4
A: TURN OFF WATER
B: DRAIN WATER
Flush toilet to drain most of the water from the tank.
C: USE SPONGE OR TOWEL TO SOAK UP
EXCESS WATER IN TANK
FLUSH
STEP 1: PREPARE TANK
Towel
Sponge
5
LEFT
LEFT
A: REMOVE CONNECTOR
Remove water supply
connector from bottom of fill
valve by twisting connector
nut to the left (clockwise).
B: REMOVE OLD LOCKNUT
Below tank, twist locknut
to the left (clockwise) to
remove from fill valve.
C: REMOVE OLD FILL VALVE
Drain any excess water
into bucket by removing fill
valve from tank.
(Pull fill valve up)
STEP 2: REMOVE OLD FILL VALVE
Bucket
(Optional)
Pliers
(Optional)
TURN
CLOCKWISE
To Next Page
