Fluke Biomedical IMPULSE 6000D User Manual

Defibrillator/Transcutaneous Pacemaker Analyzer
Instrument Familiarization
5
Table 2. Top-Panel Controls and Connections
Item Name Description
1 ECG lead connectors
Outputs of low-level ECG signals (RA/R, LL/F, LA/L, RL/N, V1/C1, V2/C2, V3/C3, V4/C4,
V5/C5, and V6/C6).
2 Backlight button Turns the LCD display backlight on and off.
3 Power button Turns the Analyzer on and off.
4 Navigation buttons Cursor control buttons for navigating menus and lists.
5 Defib connectors Defibrillator connections (Shown with removable defib paddle contact plates installed).
6 Function softkeys
Keys F1 through F5 are used to select from a number of selections that appear in the LCD
display above each function softkey.
7 Setup button Opens the setup menu.
8 ECG button Opens the main menu for ECG test functions.
9 Pacemaker inputs Input for low-level Pacer signal (7000DP only).
10 Pacer button Opens the main menu for pacer test functions (7000DP only).
11 Defibrillator button Opens the main menu for defibrillator test functions.
