Fluke Biomedical IMPULSE 6000D User Manual

Defibrillator/Transcutaneous Pacemaker Analyzer
Using Defibrillator Test Elements
63
Table 8. Charge Time Test Custom Parameters
Parameter Description
Preset Energy The energy (in Joules) used for the test
The field user is prompted to set the defibrillator to this value.
ECG Waveform The ECG waveform that the Analyzer should simulate during the test
Synchronization Time Test
The Synchronization Time test determines the ability of
the defibrillator to synchronize the discharge of its output
pulse with the simulated ECG waveform generated by the
Analyzer. Synchronization Time test measurements are
listed in Table 9. The Synchronization Time test custom
parameters are shown in Table 10.
Note
This test element supports the Auto Advance
Test Guide Setting.
Table 9. Synchronization Time Test Measurements
Measurement Unit of Measure Description
Sync Time seconds The delay between the top of the ECG wave and the discharging of the
defibrillator pulse
Energy Joules Amount of energy discharged by the defibrillator
Peak Voltage Volts Peak voltage detected during the discharge
Peak Current Amperes Peak current detected during the discharge
