Fluke Calibration 8588A - CONFig:<meter_fn>

8588A/8558A
Remote Programmer's Manual
14
In the command set below, the short form of parameters MINimum, MAXimum
and DEFault are used for brevity, the long form can be used if preferred.
CONFig:<meter_fn> <parameters>
:CONFigure:CAPacitance [<range>|MIN|MAX|DEF [,<resolution>|MIN|MAX|DEF]]
:CONFigure:CURRent:AC [<range>|MIN|MAX|DEF [,<resolution>|MIN|MAX|DEF]]
:CONFigure:CURRent:DC [<range>|MIN|MAX|DEF [,<resolution>|MIN|MAX|DEF]]
:CONFigure:XCURrent:AC [<range>|MIN|MAX|DEF [,<resolution>|MIN|MAX|DEF]]
:CONFigure:XCURrent:DC [<range>|MIN|MAX|DEF [,<resolution>|MIN|MAX|DEF]]
:CONFigure:VOLTage:AC [<range>|MIN|MAX|DEF [,<resolution>|MIN|MAX|DEF]]
:CONFigure:VOLTage:DC [<range>|MIN|MAX|DEF [,<resolution>|MIN|MAX|DEF]]
:CONFigure:RESistance [<range>|MIN|MAX|DEF [,<resolution>|MIN|MAX|DEF]]
:CONFigure:FRESistance [<range>|MIN|MAX|DEF [,<resolution>|MIN|MAX|DEF]]
:CONFigure:FREQuency [DEFault[,gate_time|MIN|MAX|DEF]]
:CONFigure:PERiod [DEFault[,gate_time|MIN|MAX|DEF]]
:CONFigure:POWer no parameters
:CONFigure:TEMPerature[:TRANsducer]:TCouple [<type>[,DEFault[,<resolution>|MIN|MAX|DEF]]]
:CONFigure:TEMPerature[:TRANsducer]:RTD [<DEFault >[,DEFault[,<resolution>|MIN|MAX|DEF]]]
:CONFigure:TEMPerature[:TRANsducer]:TRTD [<DEFault >[,DEFault[,<resolution>|MIN|MAX|DEF]]]
:CONFigure:TEMPerature[:TRANsducer]:FRTD [<DEFault >[,DEFault[,<resolution>|MIN|MAX|DEF]]]
CONFigure?
Returns the setup configured by the last CONFigure or
MEASure? See Note [6].
Notes for These Commands
Note 1:
CONFigure:<meter_fn> <parameters> forces the trigger system state to:
• INITiate:CONTinuous OFF
• ARM:LAYer2:SOURce IMMediate
• ARM:LAYer2:DELay 0 (ARM2:DELay:AUTo is set to OFF)
• ARM:LAYer2:COUNt 1
• ARM:LAYer1:SOURce IMMediate
• ARM:LAYer1:COUNt 1
• ARM:LAYer1:DELay 0 (ARM2:DELay:AUTo is set to OFF)
• TRIGger:SOURce IMMediate
• TRIGger:COUNt 1
• TRIGger:DELay 0.0 (TRIGger:DELAY:AUTO is set to OFF)
• TRIGger:HOLDoff AUTO
