Fluke 1770 Series Instructions

4
Supported Clamp Models
Sensitivity Range Adapter
Scale
Factor
Range
i1000s AC
100 mV/A
10 mV/A
1 mV/A
0.1 A to 10 A
0.1 A to 100 A
1 A to 1000 A
1 V
0.01:1
0.1:1
1:1
Auto
i3000s AC
10 mV/A
1 mV/A
0.1 mV/A
1 A to 30 A
1 A to 300 A
1 A to 3000 A
1 V
0.1:1
1:1
10:1
Auto
i310s AC/DC
[1]
10 mV/A
1 mV/A
30 A
300 A
1 V
0.1:1
1:1
Auto
i400s AC
10 mV/A
1 mV/A
0.5 A to 40 A
5 A to 400 A
1 V
0.1:1
1:1
Auto
80i-110s AC/DC
[1]
100 mV/A
10 mV/A
0.1 A to 10 A
0.1 A to 100 A
1 V
0.01:1
0.1:1
Auto
80i-2010s AC/DC
[1]
1 mV/A 2000 A 2.8 V 1:1 Low
i200s AC
10 mV/A
up to 200 A
+10 %
2.8 V 0.1:1 Low
i30s AC/DC
[1]
100 mV/A
up to 28 A
+10 % DC
2.8 V 0.01:1 Low
i5s AC
400 mV/A 5 A 2.8 V 0.0025:1 Low
[1] DC is only supported by the 177x PQ Analyzers.
