Fluke 179 User Manual

True-rms Multimeters
Unsafe Voltage
5
Unsafe Voltage
During a voltage measurement, the Product alerts you to the
presence of a potentially hazardous voltage. When the Product
detects a voltage ≥30 V or a voltage overload (), the
Y symbol
shows on the display to alert you to the presence of a potentially
hazardous voltage.
Test Lead Alert
To remind you to check that the test leads are in the correct
terminals,  momentarily shows on the display when you move
the rotary switch to or from the mA or A position.
XW Warning
Attempting to make a measurement with a test lead in an
incorrect terminal might blow a fuse, damage the
Product, and cause serious personal injury.
Terminals
Table 2 shows the terminals on the Product.
Table 2. Terminals
FUSED
V
1
2
3
4
aik01f.eps
Item Description

Input terminal for ac and dc milliamp measurements to
400 mA and frequency measurements.

Input terminal for ac and dc current measurements to
10 A and frequency measurements.

Input terminal for voltage, continuity, resistance, diode,
capacitance, frequency, and temperature (179 only)
measurements.
 Common (return) terminal for all measurements.

Fluke 179 Specifications

General

Frequency range	0 - 100 kHz
DC current range	0.01 - 10 A
DC voltage range	0.1 - 1000 V
Resistance range	0.1 - 50000000 Ω
Capacitance range	1 - 10000 nF
Resistance resolution	0.1 Ω
Resolution (frequency)	0.01 Hz
Resolution (DC current)	0.01 µA
Resolution (DC voltage)	0.1 mV
Resolution (temperature)	0.1 °C
Basic accuracy (frequency)	±(0.1% + 1)
Basic accuracy (DC voltage)	±(0.09% + 2)
Basic accuracy (resistance)	±(0.9% + 1)
Basic accuracy (capacitance)	±(1.2% + 2)
Temperature measurement range	-40 - 400 °C
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Manual	Yes

Weight and Dimensions

Depth	90 mm
Width	43 mm
Height	185 mm
Weight	420 g
