Fluke 365 Calibration Manual

Detachable Jaw True-rms Clamp Meter
The Meter
5
The Meter
Clamp Meter
1
fig_01_365.eps
Figure 1. The Meter
Specifications
Electrical Specifications
AC Current
Range .....................................................200.0 A
Resolution...............................................0.1 A
Accuracy .................................................2 % ±5 digits (45 – 65 Hz)
2.5
% ±5 digits (65 – 400 Hz)
Crest Factor ............................................2.5 @ 125 A
1.55 @ 200 A
Add 2 % for C.F. >2
DC Current
Range .....................................................200.0 A
Resolution...............................................0.1 A
Accuracy .................................................2 % ±5 digits
AC Voltage
Range .....................................................600.0 V
Resolution...............................................0.1 V
Accuracy .................................................1.5 % ±5 digits (45 – 400 Hz)
DC Voltage
Range .....................................................600.0 V
Resolution...............................................0.1 V
Accuracy .................................................1 % ±5 digits
Resistance
Range .....................................................600.0 Ω/6000 Ω
Resolution...............................................0.1 Ω/1 Ω

Fluke 365 Specifications

General

Measuring category	CAT III 600V
Product color	Black, Red, Yellow
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	46 mm
Width	65 mm
Height	225 mm
Weight	275 g
