Fluke 365 Calibration Manual

Detachable Jaw True-rms Clamp Meter
Calibration Adjustment
9
8. See Table 4 fand apply each required output from the Calibrator to the Product.
9. Wait for the reading to bec
o
me stable.
10. Push to confirm and advance to each next step.
11. When the adj
ustment is complete, disconnect the Power Supply, replace the batt
eries
and reattach the battery
compartm
ent door and tighten the screw.
Table 4. Adjustment Procedure
Test
(Switch Position)
Product
LCD
Reading
Action
C000 Calibrator output 600 V @ 50 HZ, allow the reading to stabilize, wait 4
seconds, Push 
C001 Calibrator output 300 V @ 50 HZ, allow the reading to stabilize, wait 4
seconds, Push 
C002 Calibrator output 300 V @ 100 HZ, allow the reading to stabilize, wait
4 seconds, Push 
C003 Calibrator output 300 V @ 200 HZ, allow the reading to stabilize, wait
4 seconds, Push 
C004 Calibrator output 300 V @ 300 HZ, allow the reading to stabilize, wait
4 seconds, Push 
C005 Calibrator output 300 V @ 400 HZ, allow the reading to stabilize, wait
4 seconds, Push 
K
AC Volts
Save Push 
C006 Calibrator output 0 V, allow the reading to stabilize, wait 4 seconds,
Push 
C007 Calibrator output 600 V, allow the reading to stabilize, wait 4 seconds,
Push 
L
DC Volts
Save Push 
C008 Calibrator output 0 Ω, allow the reading to stabilize, wait 4 seconds,
Push 
C009 Calibrator output 600 Ω, allow the reading to stabilize, wait 4
seconds, Push 
C010 Calibrator output 660 Ω, allow the reading to stabilize, wait 4
seconds, Push 
C011 Calibrator output 6000 Ω, allow the reading to stabilize, wait 4
seconds, Push 

Ohms
Save Push 

Fluke 365 Specifications

General

Measuring category	CAT III 600V
Product color	Black, Red, Yellow
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	46 mm
Width	65 mm
Height	225 mm
Weight	275 g
