Fluke 568 - Deleting Individual Data Records; Buttons and Connector

Infrared Thermometers
Buttons and Connector
15
Deleting Individual Data Records
To delete individual records, press the View softkey and then use the down and
up arrow softkeys to access the desired record. Once the desired record is
shown, press the Yes softkey to delete the record. To cancel data deletion, pull
the trigger.
Buttons and Connector
Table 5 shows the buttons and connector used for the thermometers.
Table 5. Buttons and Connector
Button/
Connector
Description

(561)
Press
 and then press

to toggle between the MIN, MAX, and DIF options.

(561)
Selects the emissivity setting. You can toggle between LO (0.3), MED (0.7), or HI
(0.95) using

.

The

button is used to show the MIN, MAX, and DIF functions in the secondary
display, whichever was pressed most recently.
K-type thermocouple probe used to make contact temperature measurement.
