56x
Users Manual
20
Storing Data
The 566 thermometer can store up to 20 data records. The 568 thermometer can
store up to 99 data records. The following information is stored in each record:
• Record number
• IR and probe temperature in °F or °C
• Date/Time
• Emissivity
• Max/Min/Avg/Dif Temperature (if enabled)
For more information, see “Save”.
Downloading Data
The stored data of the 568 can be downloaded to a personal computer (PC) via
the included USB cable and the included FlukeView Forms Documenting
Software. See the FlukeView Forms documentation for details. The USB input
is located on the top of the thermometer next to the external probe input
(see Figure 9).
Note
To prevent incorrect readings, do not perform a temperature
measurement of an earthed conductor while the 568 is connected to
a PC that is earthed by a three-phase grounding plug.
1
2
eyl03.eps
Figure 9. Thermocouple and USB Connections
