Installation
Mains Voltage Selection 2
2-3
Mains Voltage Selection
The 5730A Calibrator automatically detects the main line voltage when the soft power
switch is pushed and configures itself to work at that voltage level. Nominal mains
voltages ranging from 100 Vrms -120 Vrms and from 220 Vrms -240 Vrms ( ±10 %) are
acceptable, with frequencies from 47 Hz to 63 Hz.
Warnings
To prevent possible electrical shock, fire, or personal injury, the
mains fuse must be selected to match the input voltage. While
the product automatically detects the mains line voltage, the
fuse must be manually selected. See Table 7-1 for replacement
fuses.
The Calibrator comes with the appropriate line power plug for the country of purchase. If
a different type is necessary, refer to Table 2-2 and Figure 2-1. They list and show the
mains line power plug types available from Fluke Calibration.
Table 2-2. Line Power Cord Types Available from Fluke Calibration
Type Fluke Option Number
North America LC-1
Universal Euro LC-3
United Kingdom LC-4
Switzerland LC-5
Australia LC-6
South Africa LC-7
Brazil LC-42
Universal EuroNorth American/Japan United Kingdom
Australia/China
Swiss
South Africa Brazil
LC-1
LC-3
LC-4
LC-5
LC-6
LC-7 LC-42
hhp004.eps
Figure 2-1. Available Mains Power Cord Types
