Note
mA functions are only available on the lower
display.
• mA measure = Milliamps measure without loop
power
• mA w/24V = Milliamps measure with loop power
• mA source = Milliamps source
• mA sim = Milliamps simulate an external supply from
the UUT
• VOLTS = Voltage Measure
• RTD = RTD Temperature Measurement (if a probe is
connected)
Table 4 shows functions available at the same time. An X
in a column shows that the mode in the active display is
not available if the mode in that row is in operation on a
different display.
Table 4. Mode Concurrency
OTHER DISPLAYS
Current Display
[P1] [EXT] [P1] ST [EXT] ST mA
mA
Loop
VOLTS RTD
[P1]
[EXT]
[P1] ST X X X X X
[EXT] ST X X X X X
mA X X X X
mA Loop X X X X
Volts X X X X
RTD
X = Not a valid mode
