8024B
ACCURACY
DC
to
200
Hz
.....
0.2
ee
eee
eee
+2%
of
range
900
Hz
to
1
kHz
..........-46-
<I00A
add
+3%
reading
>100A
add
+6%
reading
CALIBRATION
CYCLE
........-.
1
year
FREQUENCY
RESPONSE
......
de
to
1.0
kHz
RECOMMENDED
LOAD
.......
23.0
kO
TEMPERATURE
RANGE
.......
+15°C
to
+35°C;
for
specified
accuracy
-10°C
to
+50°C;
storage
and
operation
at
reduced
accuracy.
HEATING
LIMITATION
........
Prolonged
operation
above
200A
ac
or
|
kHz
can
cause
damage
to
the
Y8100.
WORKING
VOLTAGE
RATING
.
Core
to
output;
600V
dc
or
480V
ac
Maximum
output
to
ground;
42V
dc
or
30V
ac
APERTURE
SIZE
.......-+00005
3/4”
(19
mm)
diameter
SIZE-OVERALL
.......-
0000
eee
9”
x
4-1/2”
x
1-7/
16”
(230
mm
x
115
mmx
37
mm)
WEIGHT
<u
hwnd
ikon
cake
av
eee
14
ounces
(0.4
kg),
with
batteries
POWER
....
cece
eee
eee
eee
neee
Four
“AA”
cells
BATTERY
LIFE
........-2--0065
Alkaline-20
hours
continuous
6-51.
AC
CURRENT
TRANSFORMER
(Y8101)
6-52.
Introduction
6-53.
The
Model
Y8101
(Figure
6-1)
isa
small
clamp-on
current
transformer
designed
to
extend
the
current
measuring
capability
of
an
ac
current
meter
up
to
150
amperes.
A
clamp-on
coil
desinged
into
the
probe
allows
measurements
to
be
made
without
breaking
the
circuit
under
test.
This
coil
serves
as
the
secondary
of
a
1:1000
transformer.
The
current-carrying
conductor
being
measured
serves
as
the
primary.
6-54. Specifications
CURRENT
RANGE
........-++--
2A
to
ISO0A
ACCURACY,
(48
Hz
TO
10
kHz)
.
+2%,
10A
to
150A
+8%,
2A
to
10A
DIVISION
RATIO
.......--0006-
1000:
|
WORKING
VOLTAGE
..........
300V
ac
rms
maximum
INSULATION
DIELECTRIC
WITHSTAND
VOLTAGE
.......
3
kV
rms
MAXIMUM
CONDUCTOR
SIZE.
7/16”
(1.11
cm)
6-55.
SAFETY
DESIGNED
TEST
LEAD
SET
(Y8132)
6-56.
This
test
lead
set
is
equivalent
to
the
set
originally
supplied
with
the
8020B
multimeter.
The
set
includes
one
red
and
one
black
test
lead.
Each
probe
has
an
anti-slip
shoulder
near
the
test
tip
and
is
connected
to
the
multmeter
via
a
safety-designed
shrouded
banana
connector.
This
set
will
fit
John
Fluke
instruments
with
safety-designed
input
jacks.
6-9
