Fluke 9040 User Manual

1
Introduction
The Fluke 9040 Phase Rotation Indicator (the 9040 or the Product) is a handheld
instrument designed to detect the rotary field of three-phase systems.
How to Contact Fluke
Fluke Corporation operates worldwide. For local contact information, go to our website:
www.fluke.com
To register your product, view, print, or download the latest manual or manual supplement,
go to our website.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
+1-425-446-5500
fluke-info@fluke.com

Fluke 9040 Specifications

Operating Environment

operating temperature range	0 °C to +40 °C
pollution degree	2
type of protection	IP 40

Power

fuse rating	500 mA / 1000 V
power supply	From unit under test
maximum operating voltage	690 V

Safety

electrical safety standard	IEC 61010-1/EN 61010
protection levels	CAT III/600 V to ground, CAT IV/300 V to ground
nominal voltage for rotary field direction	40 to 690 V ac

Weight and Dimensions

size	124 x 61 x 27 mm
weight	200 g
fuse size	6.3 x 32 mm
