18 Specifications and Operation DATAPAQ TP3
The key differences between the three battery types, in use, are as follows.
NiMH Alkaline Lithium
Label on battery housing Green Blue Red
Logger’s operating
temperature (internal)
−40°C to 70°C
−40°F to 158°F
−40°C to 55°C
−40°F to 131°F
−40°C to 110°C
−40°F to 230°F
Rechargeable Yes No No
Battery life
(10 channels, sample interval 1 min.,
logger temperature 70–100°C/
158–212°F, no telemetry)
200 hrs (between
charges)
(see p. 21)
450 hrs
(see p. 24)
500 hrs
(see p. 25)
Charge level shown by Insight
(p. 19)
Yes Yes No
Special safety measures No No Yes (see p. 27)
Disposal (p. 34) Return to Fluke
Process Instruments
Recycling center Recycling center
(see also p. 28)
Interchangeable battery-packs and housings:
NiMH rechargeable (left, p. 21), alkaline (center, p. 23) and lithium (right, p. 25).
The logger automatically detects the type of battery in use, which prevents
damage to non-rechargeable batteries if the charger is connected by mistake.
To remove the battery housing from the logger (in order to replace with a
new one or to change the battery type in use), see p. 23.
For disposal of batteries, see p. 34.
When the communications lead is attached, the logger is powered via USB.
Batteries can be left in the logger, but they are not then required (except when the
logger is being reset for a non-telemetry run; see p. 41).
