Page #7 background image
True-rms Multimeters
Display
5
F K Display hold enabled. Display freezes present reading.
114, 115, & 117
G M
VWX
MIN MAX AVG mode enabled.
Maximum, minimum, average or present reading displayed
114, 115, & 117
H (Red LED) Voltage presence through the non-contact VoltAlert sensor
117
I
LoZ
The Meter is measuring voltage or capacitance with a low input
impedance.
114, 115 & 117
J nµF mVµA
MkΩ kHz
Measurement units.
114, 115, & 117
K DC AC Direct current or alternating current
114, 115 & 117
L
N
Battery low warning.
114, 115, & 117
M 610000 mV Indicates the Meter’s range selection.
114, 115, & 117
N (Bar graph) Analog display.
114, 115, & 117
O Auto Volts
Auto
Manual
The Meter is in the Auto Volts function.
Autoranging. The Meter selects the range for best resolution.
Manual ranging. User sets the Meter’s range.
114 & 117
114, 115, & 117
114, 115, & 117
P + Bar graph polarity
114, 115, & 117
Q 0L W The input is too large for the selected range.
114, 115, & 117
R LEAd W Test lead alert. Briefly displayed whenever the Meter’s
function switch is rotated to or from any A position.
115 & 117
