CH1-CH6： 表示接收机的相应通道；
BAT： 表示用于对码和输入电源的通道；
接收机
10. peration instruction
10. 01.
10. 02.
接收机操作说明
接口说明
Receiver and servo connections
接收机与伺服器连接
充电接口
开关
接电池
接收机
(CH1)
(CH2)
(CH3)
(CH4)
注意: 为保证良好的遥控距离,请将接收机天线与飞机机身垂直放置并远离金属物体。
Digital propotional radio control system
FS-I4
8
To Battery
Charging Jack
Switch Harness
Receiver
Receiver
Connector instruction
CH1-CH6: represents corresponding channels.
BAT: represents the binding channel and power supply channel.
Note: To ensure good remote distance, please set the receiver antenna
and the aircraft fuselage vertically and leave away from metal objects.
