5.3 Fpv fly
This drone includes the video transmitter for FPV flight. You can
experience FPV flight after purchasing FPV glasses. The following is the
description of the video transmitter in this product
1.Use the buttons to change the power
Long press the button for 10 seconds, then short press to switch the power
to 25MW / 200MW / 600MW
25mW
200mW
600mW
FR LED
CH LED
Solid circle means light on, hollow circle means light off
The power indicator shows the current power:
25mW
200mW
600mW
Power indicator
Flash 1,stop 3s
Flash 2,stop 3s
Flash 3,stop 3s
