FlySky FS-i6X - Appendix; Detailed Equipment Parameters

appendix：
Detailed parameters of equipment：
Brand: Eachine
Item Name: Wizard X220 V2 5 Inch 4S FPV Racing Drone PNP
Drone Weight: 407g (with Camera Mount)
Frame Kit
Wheelbase: 225MM
Floor thickness: 2.0MM
Upper board thickness: 2.0MM
X board thickness: 2.0MM
The thickness of the side panel of the camera: 1.5MM
Arm thickness: 5.0MM
Frame material: T300 carbon fiber
Motor
Motor KV: 2550RPM/V
No-load current (Io/10V): 1.35A
Adipocytes: 3-5S
Weight: 31 grams
Maximum continuous current: 35A
Maximum continuous power: 560W
Maximum thrust: 1180g (4S/5")
Configuration: 12N/14P
Motor resistance RM: 0.0536Ω
Stator diameter: 22mm
Stator thickness: 7mm
Motor diameter: 27.7mm
Length of motor body: 19.2mm
Total shaft length: 34.2mm
Drive shaft: M5
Bolt hole spacing: 16mm
