7 Technical data
Technical data
Parameter US01B.M8 / US04B.M8
Detection range 8 mm [0.31”]
Resolution 0.2 mm [0.007”]
Measuring rate 2 ms
Output signal 0 to 10 VDC
0V if detection area is fully covered
10V if detectionaria is not covered at all
5V if material edge is centered in the detection
area, LED is active
Power supply 24 VDC (18 to 30 VDC)
Connecting cable M8 connector 4
-
pole
Temperature range 0 to 60°C [32 to 140°F]
Protection class IP 67
Table 6: technical data
