5 Operation
5.1 Denomination of the sensor position
Left and right are always seen in direction of the running web.
Figure 3: Terms on steering frames BKS_309.ai
Terms
Position Description
1 Entry side
2 Exit side
3 Rolling direction
4 Sensor axis
5 Sensor axis left
6 Web edge left
7 Sensor axis right
8 Web edge right
Table 3: terms sensor position
