Focusrite Saffire - Technical Specifications

Specifications
ANALOGUE INPUTS
Mic: 2 x XLR on front panel
Mic Gain: +13 dB to + 60 dB
Line: 2 x 1/4 TRS Jack
Line Gain: -10 dB to +36 dB
Instrument: As above, switched to Instrument
Instrument Gain: +13 dB to +60 dB
ANALOGUE OUTPUTS
Line level: 8 x 1/4 balanced TRS Jack
Nominal output level: 0 dBFS = 16 dBu, electronically balanced
All outputs are useable as monitoring outputs
DIM switch: 12dB attenuation
DIGITAL I/O
2 x SPDIF (RCA phono) on rear panel (24-bit, 192kHz)
Output transformer isolated
MIDI I/O
1 in / 1 out (and Thru) on rear panel
FIREWIRE
2 x S400 ports
POWER
Either via FIREWIRE or external PSU (included)
HEADPHONE MONITORING
2 x 1/4 TRS Jack on front panel (mirrors outputs 5-8)
MIC
Frequency Response: 20Hz - 20kHz +/- 0.1 dB
THD+N: 0.001% (measured at 1kHz with 20Hz/22kHz bandpass
filter)
Noise: EIN = >120 dB (measured at 60 dB of gain with 150‰
termination and 20Hz/22kHz bandpass filter)
LINE
Frequency Response: 20Hz - 20kHz +/- 0.1 dB
THD+N: 0.001% (measured with 0 dBFS input and 22Hz/22kHz
bandpass filter)
Noise: -88 dBu (22Hz/22kHz bandpass filter)
INSTRUMENT
Frequency Response: 20Hz - 20kHz +/- 0.1 dB
THD+N: 0.004% (measured with 0 dBu input and 20Hz/22kHz
bandpass filter)
Noise: -87 dBu (20Hz/22kHz bandpass filter)
DIGITAL PERFORMANCE
Clock Source: Internal clock or sync to word clock from SPDIF inputs
A/D Dynamic Range 104 dB A weighted
D/A Dynamic Range 110 dB A weighted
Clock Jitter < 250 pico seconds
Sample rate 44.1 to 192 kHz
WEIGHT and DIMSENSIONS
1.1kg
6.5cm x 17cm x 17cm
POWER REQUIREMENTS
12v AC @ 1A
SYSTEM REQUIREMENTS
Macintosh
OS: OS X 10.3.3 or later
CPU/Clock: G3/800MHz, G4/700MHz
G4/1.2GHz or higher recommended for 192kHz operation
Memory: 256MB minimum
PC
OS: Microsoft Windows XP Home Edition/XP Professional
CPU/Clock: Pentium, Celeron or Pentium compatible processor
900MHz or higher
Memory: 256MB minimum
