22
Fig. 25
20. Remove bolt and reinstall the washer and bolt.
Place retainer over bolt and secure with nut and
washer.
Apply
petrol-gel
Fig. 26
21. Lubricate body of stream divider with petrol-gel
and reinstall.
22. Plug gearmotor power cord into electrical box.
Fig. 24
18. Using a wrench, rotate the shaft clockwise to align
the keyways in the gear housing and the shaft so as
to accept the key.
19. Insert the key into the keyway.
