Assembly Instructions
a.Attach the Front support (21#) to the base frame and Secure them with 1 pc M10*70 Carriage
bolt(58#),1pcφ10 washer(69#),1pc M10 Aircraft nuts(68#) .
b.Attach the one end of seat pad support(5#) to the front vertical frame and secure them with 2pcs
M10*70 Carriage bolt(58#),1pc bracket(37#),2pcs
φ
10 washers(69#),2pcs M10 Aircraft nuts(68#).
c.Attach another end of the seat pad support(5#) onto the front support(21#) and secure them with 2pcs
M10X20 Allen bolt (63#),2Pcs
φ
10 washers(69#).
Step 6
10
