Assembly Instructions
Step 7
a.Attach the Leg developer (14#) to the bracket of the seat pad support (5#) and Secure them with 1 pc
Axle(55#),2pcsφ10 washer(69#),2pcs M10 Aircraft nuts(68#) .
b.Attach one end of front connection frame (15#) to the leg developer (14#) and secure them with 1 pc
Axle(55#),2pcsφ10 washer(69#),2pcs M10 Aircraft nuts(68#) .
c.Insert the leg press frame(16#)into the front connection frame (15#) and select the desired height with
the lock knob(46#).
