Force JX-DS925 - Page 17

Assembly Instructions
Step 12
Attach the big bracket(35#) to the right sliding frame(34#) and secure them with 1pc M12X90 Allen
bolt(57#),2pcs φ12 washer (67#) and 1 pc M12 aircraft nut(66#).
Repeat the same way to install the another one.
16
