Important: Study and follow the diagram carefully.
A Attach the end of the 3020 MM butterfly cable(82#) to the hook .
B. place 1X pulley (103#) below the cable , Secure the pulley to the swivel pulley bracket(12#) with
1PC M10X45 Allen bolt (61#),2pcs φ10 washer (69#) and 1pcM10 Aircraft nut (68#).
C Draw the cable around the pulley and downwards ,Place 1pc pulley (103#) onto the cable , Secure
the pulley with cross double floating pulley bracket(11#) together with the same way in A.
D Draw the cable around the pulley and upwards, Install another pulley with the same way in above A
and B.
