Forcepoint Next Generation Firewall Hardware Guide | Models 330, 331, 335, 335W
Model 330 and 331 features
The figures and tables show the appliance components and features.
Front panel
This panel has the following parts.
1 3
5
2
6 7
4
1 Power button. The indicator on the button shows if the power is on.
2 Indicator lights
3 Console port (speed 115,200 bps)
4 USB port
5 USB 3.0 port
6 Fixed Ethernet ports 0-3. From left to right, numbered eth0, eth1, eth2, and eth3.
7 Fixed Ethernet ports 4-7. From left to right, numbered eth4, eth5, eth6, and eth7.
Back panel
This panel has the following parts.
1 2
1 CFast Card
2 19V DC power connectors A and B from left to right
CAUTION: The power connectors are intended to provide power to the Forcepoint
appliance only. Do not connect other devices to the power connectors. Use only the power
adapter delivered with the Forcepoint appliance to power the appliance.
3
