43. Install and align the hood. Tighten to 9 Nm (80 lb-in). Connect the hood light connector and locator
pin to the hood. Clip the ground strap to the hood on the right hand side.
44. Install the negative battery cable.
45. Fill the cooling system.
46. Fill the engine with oil.
47. Fill the power steering system.
48. Evacuate, pressurize, leak test, and recharge the A/C system.
49. Check the operation of the engine.
A — Tighten to 2-3 Nm
(18-27 Lb-In)
B — Tighten to 1-2 Nm
(9-18 Lb-In)
