11. Installthrottle body and newintake manifold gasketas outlined in Section 03-04B . Install coil and
bracket assembly (Ranger only). Tighten retaining nuts to 16-20 Nm (12-15 lb-ft).
12. Install wire harness standoffs to rocker arm cover studs and connect wires to spark plug and ignition
coil.
13. Install fuel supply and return lines to fuel injection supply manifold as outlined in Section 03-04B .
14. Install fuel tube clips.
15. Install upper radiator hose and heater water hoses. Tighten hose clamps securely.
16. Connect vacuum lines to premarked locations.
17. Connect electrical connections of:
Radio ignition interference capacitor
Idle air control valve
Engine coolant temperature sensor
Distributor
Ignition coil
Radio ignition interference capacitor
Water temperature indicator sender unit
EGR pressure sensor, if equipped
EGR vacuum regulator control, if equipped
Refer to Section 18-01 for further information.
18. NOTE: Engine coolant is corrosive to all engine bearing material. Replacing oil after removal
of a coolant carrying component prevents failure later.
Fill and bleed cooling system with specified coolant and proper mixture.
19. Replace crankcase oil and oil filter.
20. Install air cleaner outlet tube to throttle body and MAF sensor (12B579). Tighten retaining clamps to
1.9 Nm (17 lb-in).
21. Install closure hose to valve cover and air cleaner outlet tube.
3 — Nut (Part of 12A310)
4 12A310 Ignition Coil and Bracket Assembly
5 — Stud (Part of 9E926)
6 12N004 Ignition Coil Mounting Bracket
7 — Exhaust Manifold Stud
(Part of 9430)
A — Tighten to 8-12 Nm
(6-9 Lb-Ft)
B — Tighten to 16-20 Nm
(12-15 Lb-Ft)
