valley preventing any particles to enter oil drain holes or cylinder head. Use a suitable solvent to
remove old rubber sealant.
2. Lubricate valve tappets and bore with Engine Assembly Lubricant D9AZ-19579-D or equivalent
meeting Ford specification ESR-M99C80-A.
Item Part Number Description
1 — Bolt (Part of 6K564)
2 6K564 Tappet Guide Plate and Retainer
3 — Cylinder Block Assembly Tappet Bore
(Part of 6010)
4 — Washer (Part of 6K564)
5 — Cylinder Block Assembly Guide Plate Retainer
(Part of 6010)
6 6500 Valve Tappet
7 6K512 Valve Tappet Guide Plate
A — Tighten to 10-14 Nm
(7-10 Lb-Ft)
Page
3
of
6
1997 Aerostar/Ranger
2011
-
04
-
27
file://C:\TSO\tsocache\VDTOM_5368\SVK~us~en~file=SVK31B16.HTM~gen~ref.HTM
