Ford 2001 Windstar Workshop Manual

Symptom Chart
Pinpoint Tests
Symptom Chart
Condition Possible Sources Action
 No communication with the instrument cluster (IC)  Central junction box (CJB)
fuse(s):
 9 (10A).
 14 (10A).
 16 (10A).
 28 (10A).
 10 (15A).
 Circuitry.
 J1850 communication
network (SCP).
 Instrument cluster.
 REFER toSection 413-01.
 No communication with the message center
module (MCM)
 Central junction box (CJB)
fuse(s):
 9 (10A).
 14 (10A).
 16 (10A).
 28 (10A).
 10 (15A).
 Circuitry.
 J1850 communication
network (SCP).
 Instrument cluster.
 GO to Pinpoint Test A.
 No communication with the front electronics
module (FEM)
 Battery junction box (BJB)
fuse(s):
 2 (10A).
 13 (10A).
 Circuitry.
 Front electronic module
(FEM).
 REFER toSection 419-10.
 No communication with the rear electronics
module (REM)
 Central junction box (CJB)
fuse(s):
 8 (20A).
 16 (10A).
 Circuitry.
 Rear electronic module
(REM).
 REFER toSection 419-10.
 The compass is inoperative  Circuitry.
 Compass sensor module.
 Instrument cluster.
 GO to Pinpoint Test B.
 The message center display is blank — while not
on the blank display section
 Instrument cluster.  INSTALL a new instrument cluster. REFER toSection 413-01.
 The message center is not operating correctly  Instrument cluster.
 Message center switch.
 GO to Pinpoint Test C.
 The message center switch does not operate
correctly
 Circuitry.
 Message center switch.
 Instrument cluster.
 GO to Pinpoint Test D.
 The indicator does not operate correctly —
outside temperature display
 Circuitry.
 Instrument cluster.
 Front electronic module
(FEM).
 Ambient temperature
sensor.
 GO to Pinpoint Test E.
 The indicator does not operate correctly —
charge system display
 Circuitry.
 Generator.
 Powertrain control module
(PCM).
 Instrument cluster.
 REFER toSection 413-01.
 The indicator does not operate correctly —
washer fluid level display
 Circuitry.
 Washer fluid level switch.
 Front electronic module
(FEM).
 Instrument cluster.
 REFER to Section 413-01.
 The indicator does not operate correctly — door
ajar display
 Circuitry.
 Door ajar switch(es).
 Front electronic module
(FEM).
 Rear electronic module
(REM).
 Instrument cluster.
 REFER toSection 413-01.
 The indicator does not operate correctly — low
fuel level display
 Circuitry.
 Fuel level sender.
 Rear electronic module
(REM).
 Instrument cluster.
 GO to Pinpoint Test F.
 The lampout warning indicator is inoperative  Circuitry.
 Front electronic module
(FEM).
 Rear electronic module
(REM).
 Instrument cluster.
 GO to Pinpoint Test G.
 The indicator does not operate correctly —
distance to empty, average fuel economy
 Circuitry.
 Instrument cluster.
 Powertrain control module
(PCM).
 Antilock brake system
(ABS).
 CHECK the operation of the speedometer, the fuel gauge and the
odometer. If inoperative, REFER to Section 413-01.
Page
4
of
12
