1. Open the hood.
2. Remove the cover.
3. Disconnect the electrical connector.
4. Release the clip and remove the bulb.
Side Lamp
1. Remove the cover.
2. Remove the bulb holder.
3. Remove the bulb.
Vanity Lamp
1. Position the visor in the down position.
2. When removing the vanity lamp, be
careful not to damage the roof trim.
Using appropriate plastic spatula,
insert it between the vanity mirror and
the roof trim and release the metal
retaining clip.
3. Remove the lamp.
4. Remove the bulb.
Front Fog Lamps
Note: Do not separate the fog lamp bulb
from the bulb holder
143
Ecosport (CBW) Vehicles Built From: 01-12-2014 Vehicles Built Up To: 29-03-2015, CG3590en enGBR, Edition date: 08/2014, First Printing
Maintenance
