1. Unlock the outer cover and the inner
cover together with the lock bracket at
the bottom.
2. Pull out the outer cover.
3. Remove the lug nuts and locking lug
nut.
4. Remove the spare wheel.
5. Install in the reverse order.
Note: When installing the spare wheel
cover, make sure you hear an audible click.
Removing a Road Wheel
WARNINGS
Park your vehicle so that you do not
obstruct the flow of traffic or place
yourself in any danger and set up a
warning triangle.
Make sure that your vehicle is on firm
and level ground with the front
wheels pointing straight ahead.
Switch the ignition off and apply the
parking brake.
If your vehicle has a manual
transmission, shift into first or reverse
gear. If your vehicle has an automatic
transmission, shift into park (P).
Make sure all passengers are out of
your vehicle.
163
Ecosport (CBW) Vehicles Built From: 01-12-2014 Vehicles Built Up To: 29-03-2015, CG3590en enGBR, Edition date: 08/2014, First Printing
Wheels and Tires
