WARNINGS
Never place anything between the
vehicle jack and your vehicle.
Make sure that the vehicle jack is
vertical to the jacking point and the
base is flat on the ground.
Do not work on your vehicle when
the jack is the only support. If the
vehicle slips off the jack, you or
someone else could be seriously injured.
Jack and Associated Tools
The vehicle jack, wheel brace, recovery
hook, warning triangle and locking wheel
nut key are located in the luggage
compartment under the floor cover, in a
tool kit.
Jacking and Lifting Points
WARNING
You must use the specified jacking
points.
Small arrow-shaped marks on
the sills show the location of the
jacking points.
A
Removing a Spare Wheel
To remove and install the spare wheel:
162
Ecosport (CBW) Vehicles Built From: 01-12-2014 Vehicles Built Up To: 29-03-2015, CG3590en enGBR, Edition date: 08/2014, First Printing
