Ford 2015 TRANSIT CONNECT - Load Carrying; Luggage Anchor Points; Rear under Floor Storage; Passenger Compartment Floor

LUGGAGE ANCHOR POINTS
E167350
Maximum Load
Value
Variant
785 lb (357 kg)Transit Courier
900 lb (408 kg)Transit Connect
REAR UNDER FLOOR
STORAGE
Passenger Compartment Floor (If
Equipped)
E78097
The under floor storage compartment is
located behind the front passenger seat.
Adjustable Load Floor (If Equipped)
E142446
Vehicles with the standard size spare tire
can adjust the load floor to two positions.
The front of the load floor can be placed
either on (for high position) or below (for
low position) the ledges behind the rear
seats. The rear of the load floor always sits
on the two small shelves located on the
liftgate trim.
141
Transit Connect (CHC) Canada/United States of America, enUSA, First Printing
Load Carrying
