Folding the seats forward
WARNING
Do not use the third row seats when
the second row seats have been
folded forward.
Note:
The centre seat must be stowed
into the right-hand seat base before the
right-hand seat is folded.
1. Pull the strap and lift the cushion.
2. Lift the lever and push the seatback
down until it locks.
Third row seats - Grand C-MAX
WARNINGS
When folding or unfolding the seats,
take care not to get your fingers
caught between the seatback and
seat frame.
Rock the seat backwards and
forwards after moving to make sure
that it is fully engaged in its catch.
Make sure the rear of the seat is
free from obstruction when moving
it rearwards.
Note:
Fully lower the head restraint when
folding the seats. See Head restraints
(page 110).
120
Seats
