Ford C-MAX 2010 - Engine Compartment Overview - 2.0 L Duratorq-Tdci (DW) Diesel

Battery: See Vehicle battery (page 196).
E
Engine compartment fuse box: See Fuses (page 173).
F
Air cleaner: No maintenance necessary.G
Engine oil dipstick
*
: See Engine oil check (page 190).
H
Screen washer fluid reservoir
*
: See Washer fluid check (page 191).
I
*
For easy identification, filler caps and the engine oil dipstick are marked in colour.
ENGINE COMPARTMENT OVERVIEW - 2.0L DURATORQ-
TDCI (DW) DIESEL
E130032
A B C D E F
GHI
