Controls and Features
49
[CF02300(ALL)12/95]
FLR/DEF
[CF02400(ALL)12/95]
Select FLR/DEF to get air to the floor and windshield defrosters
at the same time.
*
[CF02500(ALL)03/96]
V DEF
[CF02600(ALL)05/96]
Select V DEF to obtain maximum air flow to the windshield.
Rotate the temperature control into the RED area for the air
temperature required to defrost. Rotate the
H
control to
increase the air flow.
*
[CF02700(ALL)01/96]
Heating and Air Conditioning System
[CF02800(ALL)12/95]
Heating, ventilation, defrosting and defogging are accomplished
in the same way as with the heating only system. See “Heating
Only System.”
[CF02900(ALL)12/95]
With the heating and air conditioning system, if the outside
temperature is about 50˚F (10˚C) or warmer, the air will be
dehumidified to remove moisture if you select FLR/DEF or V
DEF.
[CF03100( Z)12/95]
10-1/2 pica
art:0001302-B
The control for the heating and air conditioning system
File:05cdcfz.ex
Update:Fri May 31 14:31:06 1996
