Ford Pro 48A - Fasten Charge Point onto Mounting Bracket

US Type Charger 48A Installation Manual Rev0.1
Ford Pro contact info: chargingsupport@fordpro.com and 1-800-34-FLEET
18
Screw
Torque
M6
25 kgf.cm min
21.7 lbf-in
min
#12
25 kgf.cm min
21.7 lbf-in
min
3.3.3 Fasten charge point onto mounting bracket.
1. Put the charge point on the mounting bracket.
2. Fasten charge point on mounting bracket by tightening M6 screw.
3. Please refer to the following torque.
Screw
Torque
M6
31 kgf.cm
26.9
lbf·in
