Circuits protectedColour
Ampere
rating
Fuse
Instrument cluster, reversing lamps,
direction indicators, remote free-wheel
(RFW) system
blue1510
Engine management systemsblue1511
Not used--12
Air conditioning magnetic clutchred1013
Heated rear windowyellow2014
Rear fog lampred1015
Right-hand headlampblue1516
Left-hand headlampblue1517
Front fog lampblue1518
Rear lamps, side lamps, number plate
lamp
red1019
Interior lamps, warning systemblue1520
Not used--21
Electric windowspink3022
