Ford RANGER Owner's Handbook

DETACHABLE TOW BALL
WARNINGS
Never leave the detached tow ball
arm unsecured inside the vehicle.
This would increase the risk of injury
in an accident.
When not in use, always transport
the tow ball arm securely fastened
in the luggage compartment.
Take special care when fitting the
tow ball arm as the safety of the
vehicle and the trailer depends on
this.
A 13-pin trailer socket and the tow ball arm
seat are provided underneath the rear
bumper. Turn the trailer socket down
through 90 degrees until it engages in the
correct position.
Unlocking the tow ball arm
mechanism
WARNINGS
Do not use any tools for mounting
or dismounting the tow ball arm.
Do not modify the trailer coupling.
Do not disassemble or repair the
tow ball arm.
E78801
1. Remove the plug from the seat.
2. Remove the protection cap.
3. Insert the key and turn it
anti-clockwise.
Inserting the tow ball arm
E78802
1. Remove the lock.
2. Push the lever to the left and hold it.
3. Push the lever fully forwards until the
tow ball arm is unlocked.
4. Insert the tow ball arm in to the seat.
WARNINGS
The tow ball arm may only be
inserted when completely unlocked.
Make sure that the tow ball arm is
fully engaged in the seat.
Note: The lever must be on the outside
of the case.
79
Towing
