Fuse or relay
number
Fuse amp
rating
Protected components
64 — Not used
65 30A* Fuel pump relay, Fuel injectors
66 — Powertrain control module relay
67 20A* Oxygen sensor heater, Mass
airflow sensor, Variable camshaft
timing solenoid valve, Canister
vent solenoid, Canister purge
solenoid
68 20A* Ignition coils
69 20A* Vehicle power #1 (powertrain
control module)
70 15A*
A/C clutch, Fan control relay coils
(1-3), Variable air conditioning
compressor, Auxiliary transmission
warmup, Turbo charge waste-gate
control, Electronic compressor
bypass valve, All-wheel drive
module, Positive crankcase
ventilation heater
71 — Not used
72 — Not used
73 — Not used
74 — Not used
75 — Not used
76 — Not used
77 — Not used
78 20A* Right high-intensity discharge
headlamp
79 5A* Adaptive cruise control module
80 — Not used
81 — Not used
82 — Not used
284 Fuses
2013 Taurus
Owners Guide gf, 3rd Printing, December 2012
USA (fus)
