WARNINGS
Have the passengers leave your
vehicle.
Secure the diagonally opposite
wheel with an appropriate block or
wheel chock.
Only use the vehicle jack supplied
with this vehicle to change a wheel.
Never work underneath your vehicle
when it is supported only by a jack.
E166722
WARNINGS
Make sure that the jack is vertical to
the jacking point and the base is flat
on the ground.
Make sure that the arrows on
directional tires (where fitted), point
in the direction of rotation when the
vehicle is moving forwards. If you have to
fit a spare wheel with the arrows pointing
in the opposite direction, have the tire
refitted in the correct direction by a
properly trained technician.
1. Insert the flat end of the wheel brace
between the rim and the wheel trim
and carefully remove the wheel trim.
2. Use the locking lug nut key to loosen
the locking lug nut.
3. Loosen the remaining lug nuts, but do
not remove them.
4. Raise your vehicle until the wheel and
tire is clear of the ground.
5. Remove the lug nuts and the road
wheel.
Note: Do not lay alloy road wheels face
down on the ground.
Installing a Road Wheel
WARNINGS
Make sure that the arrows on
directional tires point in the direction
of rotation when your vehicle is
moving forward. If you have to fit a spare
wheel with the arrows pointing in the
opposite direction, have the tire refitted in
the correct direction by an authorized
dealer.
Use only approved wheel and tire
sizes. Using other sizes could
damage your vehicle and will make
the National Type Approval invalid.
Do not fit run flat tires on vehicles
that were not originally fitted with
them. See an authorized dealer for
more details about compatibility.
Do not install alloy wheels using
wheel nuts designed for use with
steel wheels.
Wheel nuts are subject to change.
You must make sure that you use
only the specific wheel nuts and
wheels supplied for your vehicle. If in doubt
see an authorized dealer.
Make sure that there is no lubrication
(grease or oil) on the threads or the
interface between wheel studs and
nuts.
Note: The wheel nuts of alloy wheels and
spoked steel wheels can also be used for
the steel spare wheel for a short time
(maximum two weeks).
Note: Make sure the wheel and hub contact
surfaces are free from foreign matter.
1. Install the wheel.
