Ford Windstar 2000 - FEM Diagnostic Data and Commands

To Next Page

To Previous Page

FEM Active Command Index

PID Description Expected Value

ACCDLY Accessory Delay Relay Circuit Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

AL_EVT1 Last 8 Alarm Events DROPEN, HOODTR, IGNTAM, PANIC, T_AJAR, D_DOOR, RADIO, NOEVNT

AL_EVT2 Last 8 Alarm Events DROPEN, HOODTR, IGNTAM, PANIC, T_AJAR, D_DOOR, RADIO, NOEVNT

AL_EVT3 Last 8 Alarm Events DROPEN, HOODTR, IGNTAM, PANIC, T_AJAR, D_DOOR, RADIO, NOEVNT

AL_EVT4 Last 8 Alarm Events DROPEN, HOODTR, IGNTAM, PANIC, T_AJAR, D_DOOR, RADIO, NOEVNT

AL_EVT5 Last 8 Alarm Events DROPEN, HOODTR, IGNTAM, PANIC, T_AJAR, D_DOOR, RADIO, NOEVNT

AL_EVT6 Last 8 Alarm Events DROPEN, HOODTR, IGNTAM, PANIC, T_AJAR, D_DOOR, RADIO, NOEVNT

AL_EVT7 Last 8 Alarm Events DROPEN, HOODTR, IGNTAM, PANIC, T_AJAR, D_DOOR, RADIO, NOEVNT

AL_EVT8 Last 8 Alarm Events DROPEN, HOODTR, IGNTAM, PANIC, T_AJAR, D_DOOR, RADIO, NOEVNT

ATHFTSW Security Speed Signal notACT, ACTIVE

BLWRMTR Blower Motor notACT, ACTIVE

BRK_LVL Brake Fluid Level notOK, OK

CCNT Number Of Continuous DTCs In Module one count per bit

D_DN_SW Drivers Window Down Switch OFF, DOWN

D_DOOR Left Front Door Ajar Switch CLOSED, AJAR

D_DSRM Driver Door Unlock Disarm Switch NO, YES

D_PWPK Drivers Power Window Peak Current AMPs

D_PWRLY Drivers Power Window Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

D_SBELT Drivers Seat Belt OUT, IN

D_UP_SW Drivers Window Up Switch OFF, UP

DD_UNLK Drivers Door Unlock Output Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

DR_LOCK Drivers Door Lock Output State NO, YES

DR_UNLK All Doors Unlock Output State NO, YES

DU_WRLY Window Driver Output State notACT, ACTIVE

EXTTEMP External Temperature Sensor Unfiltered Data Degrees in celsius

HOOD_SW Hood Ajar Switch CLOSED, AJAR

HORNRLY Horn Control Driver Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

IGN_R Ignition Switch -Run Position NO, YES

L_HIGH Left High Beam Lamp Driver Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

L_LOW Low Beam Lamp Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

LF_TURN Left & Right Front Turn Lamp Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

OIL_LVL Engine Oil Level notOK, OK

OTD_SW One Touch Down Switch OFF, DOWN

P_DOOR Passengers Door Ajar Switch CLOSED, AJAR

P_DSRM Passenger Door Unlock Disarm Switch NO, YES

PARKLMP Park Lamp Output notACT, ACTIVE

PD_LOCK Passengers Door Lock NO, YES

PD_UNLK Passenger Unlock Activated NO, YES

PRK_BRK Parking Brake Switch Input OFF, ON

R_HIGH Right High Beam Lamp Driver Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

R_LOW Low Beam Lamp Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

R_WPRUN Rear Wiper Run Switch Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

RADIOSW Radio Remove Switch OFF, ON

RF_TURN Left & Right Front Turn Lamp Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

RWASHSW Rear Washer Switch Position Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

VBAT Battery Voltage Voltage

WASHRLY Washer Pump Relay Circuit Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

WFLUID Washer Fluid Level LOW, OK

WPHISP Wiper Two Speed Relay Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

WPMODE Wiper Control Mode Select WASH, OPEN, INVLD, OFF, INTVL1, INTVL2, INTVL3, INTVL4, INTVL5, INTVL6, INTVL7, LOW, HIGH, ?

WPPRKSW Windshield Wiper Park Sense notPRK, PARKED

WPRUN Wiper Run Relay Driver State Off---, Off--G, Off-B-, Off-BG, OffO--, OffO-G, OffOB-, OffOBG, On---, On--G, On-B-, On-BG, OnO--, OnO-G, OnOB-, OnOBG

Active Command Display Action

ANTI-THEFT INDICATOR COMMAND HORN OFF, ON

BATTERY SAVER & COURTESY ENTRY COURTESYL OFF, ON

DOOR LOCK CONTROL DD LOCK OFF, ON

DOOR LOCK CONTROL DD UNLOCK OFF, ON

FRONT WINDOW CONTROL DR DOWN OFF, ON

FRONT WINDOW CONTROL DR UP OFF, ON

FRONT WINDSHIELD WIPER/WASHER SPEED RLY OFF, ON

FRONT WINDSHIELD WIPER/WASHER WASH RLY OFF, ON
