Contents
Safety Instructions 2, 3
Foredom
®
Tools 4
Assembly Instructions 5-6
Assembly and Adjustment of Flexible Shaft,
Sheath and Handpiece 5
Connecting Foot or Manual Speed Controls 6
Hanging Motor Installation 6
Foredom Handpieces and Accessories 7-11
Attaching Accessories to Handpieces 8
General Accessory Recommendations 10-11
Operation —General Guidelines 12
Maintenance Procedures 12-14
Routine Cleaning and Lubrication 12-14
Replacement of Worn Shaft and Sheath 13-14
Replacement of Motor Brushes 14
Repair and Storage 14
Recommended Spare Parts and Supplies 15
Motor Hangers 15
2-Year Limited Warranty 16
Contact Information 16
Page
2
Safety Instructions
Before using your Foredom power tool,
please read safety instructions.
They are
for your protection and should always be
followed to reduce the risk of personal
injury or damage to the tool.
s
Always wear proper eye and face protection.
Wear safety glasses or face shields when-
ever you operate a Foredom or any power
tool to pre vent serious eye or face injuries.
s
Secure the workpiece or item that you are
working on
in a vise or other work holding
device. Holding it with your hand can result
in serious hand injury.
s
Always use a proper dust collection system or
wear a respirator
to pre vent the inhalation of
dust particles, polishing compounds, or
other debris into the lungs.
s
Do not wear loose fitting clothing or jewelry.
Loose clothing or jewelry can become
entangled in the rotating accessory. Do not
wear items such as neckties, necklaces, or
bracelets when operating power tools. Be
sure to
tie back or secure long hair.
s
Secure power tool to motor hanger or work
surface.
Flexible shaft power tools can
“jump” at start up or vibrate during opera-
tion. The tool should be properly secured in
order to prevent it from vibrating off of the
motor hanger, work bench or wall.
s For added safety and comfort while using
this power tool for carving or other applica-
tions, it is recommended that you wear a
heavy canvas or leather apron. It will protect
you from debris and chips as well as help
prevent injury if the handpiece slips off the
workpiece. It will also help prevent loose
clothing from getting caught in a rotating
cutter, bur or other accessory.
How-To Videos on
www.foredom.net
Click on our homepage
Video Library link where
Foredom’s National Sales
Manager shows you the
basics of using and maintain-
ing flex shaft machines.
Click to View:
1. Intro & Proper Set-up
2. Safety Guidelines
3. Handpieces &
Accessories
4. Shaft and Sheath
Maintenance – Grease
and Replace
5. Motor Maintenance–
Remove Dust, Replace
Motor Brushes
We have other product-relat-
ed videos embedded
throughout our website. We
suggest that you take the
time to watch these since
they help to clarify product
features and uses.
