FORESTADENT TRACK P - Page 19

19
GB
Compressed air connection and pressure regulator
(only Track
®
-P)
Medium-wave infrared heater
Touchpanel
Main switch
Insertion ramp for foil reception
Fixation for foil frame
Sensor window
Form pot
Insertion rail for the form pot
Granules collecting device
Mains connection (at the side)
6
1
7
2
8
3
9
4
10
5
11
Track
®
-P | Track
®
-P-ci
Pressure forming unit with automated thermoforming process to connect to the existing compressed air system. |
Pressure forming unit with automated thermoforming process and integrated production of compressed air with
reserve compressed air.*
The Track
®
-P | Track
®
-P-ci units are in accordance with the respective legal standards that are listed in the declaration of
conformity on page 66 of this operating manual.
*Pat. 19518211
1
4
8
9
10
11
5
7
6
3
2
