Troubleshooting:
Error Possible cause Possible elimination
Error 002: Disorder protection shield, microswitch
not reached or actuated
The support for the foil reception has not moved
down the red protection shield.
Make sure that the foil reception is snapped into
place, push it completely into the unit.
Error 003: Microswitch for form pot not operated
Form pot position changed during thermoforming/
switch defective.
Do not pull out the form pot during the thermo-
forming process.
Error 004: Heating position switch not reached
When the support for foil reception is raised, the
heating position switch is not reached/switch
defective.
See Error 001, »Heating switch« must light up.
Error 010: Program abort (timeout foil reception)
Foil reception was not in heating position for
more than 10 sec. during heating.
The foil reception must be pulled out only briefly
and must be pushed back into place within
10 seconds.
Error 011: Program abort (timeout form pot)
The form pot was not in thermoforming position for
more than 10 sec. at the end of the heating time.
The form pot must be in the rearmost, locked posi-
tion for the thermoforming process. If not,
the program is aborted after 10 sec.
Error 021: Disorder of the temperature
measurement
Heater was in operation for more than
10 min. / IR temperature sensor defective.
After 10 minutes of heating, the heater switches
off for safety reasons.
Only Track
®
-P-ci
Error 031: Runtime of compressor too long
Compressor needs longer than 90 seconds to build
enough pressure, pressure system leaking.
Check compressed air system.
Example, Error 001: blocked support for foil reception in the travel path downwards (motor switches off).
Move support for foil reception step by step downwards (motor
down) or upwards (motor up) in the respective end position.
(Press touch fields repeatedly)
Example: red light up, position switch is switched on.
