FortiGate-50A/50B, FortiWiFi-50B and FortiGate-100 FortiOS 3.0 MR4 Install Guide
16 01-30004-0265-20070831
Package Contents Installing the FortiGate unit
Table 1: Technical Specifications
FortiGate-50B
The FortiGate-50B package contains the following items:
• FortiGate-50B Unified Threat Management System
• one gray straight-through Ethernet cable (Fortinet part number CC300249)
• one RJ-45 to DB-9 serial cable (Fortinet part number CC300247)
• one AC adapter and power cable
• FortiGate-50B QuickStart Guide
• Fortinet Tools and Documentation CD
Figure 2: FortiGate-50B package contents
Table 2: Technical Specifications
Dimensions 8.63 x 6.13 x 1.38 in. (21.9 x 15.6 x 3.5 cm)
Weight 1.5 lb. (0.68 kg)
Power Requirements DC input voltage: 12V
DC input current: 3A
Environmental
Specifications
Operating temperature: 32 to 104 F (0 to 40 C)
Storage temperature: -13 to 158 F (-25 to 70 C)
Humidity: 5 to 95% non-condensing
Dimensions 8.5 x 1.4 x 5.8in. (21.6 x 14.8 x 3.6 cm)
Weight 1.6 lb. (0.73 kg)
Power Requirements DC input voltage: 12V
DC input current: 3A
Environmental
Specifications
Operating temperature: 32 to 104 F (0 to 40 C)
Storage temperature: -13 to 158 F (-25 to 70 C)
Humidity: 5 to 95% non-condensing
123
USB
WAN2 WAN1
DC+12V
WAN1 WAN2
POWER STATUS
INTERNAL
321
LINK / ACT
10/100
Power
Connection
RJ-45 Serial
Connection
USB
WAN2
WAN1
Power
LED
Status
LED
Internal Interface,
switch connectors
1,2,3
WAN 1,2
Interface
Internal
Interface
Documentation
Ethernet Cables:
Grey - Straight-through
FortiGate-50B
Copyright 2006 Fortinet Incorporated. All rights reserved.
Trademarks
Products mentioned in this document are trademarks.
Power Cable Power Supply
RJ-45 to
DB-9 Serial Cable
QuickStart Guide
WAN1 WAN2
POWER STATUS
INTERNAL
321
LINK / ACT
10/100
Back
Front
