Firewall Address
FortiGate-200A Administration Guide 01-28006-0072-20041105 203
3 Select OK.
Address group list
You can organize related addresses into address groups to make it easier to
configure policies. For example, if you add three addresses and then configure them
in an address group, you can configure a single policy using all three addresses.
Figure 86: Sample address group list
The address group list has the following icons and features.
Address group options
Address group options are configurable when creating or editing an address group.
Figure 87: Address group options
Address group has the following options:
Note: If an address group is included in a policy, it cannot be deleted unless it is first removed
from the policy.
Create New Select Create New to add an address group.
Group Name The name of the address group.
Members The addresses in the address group.
The Delete and Edit/View icons.
Group Name Enter a name to identify the address group. Addresses, address groups, and
virtual IPs must all have unique names to avoid confusion in firewall policies.
